Yuyao Xinguang Special Bearing Co., Ltd.

Bearing NO.	Bore	Diam(d)	Dimensionsin.mm								Dynamic load	Statie load	Weight
	(in)	(mm)	D	B	C	S	S1	G	ds	F	ratings(N)	ratings(N)	(kg)
SSUX05-13	13/16		2.4409	1.5000	0.7480	0.6260	0.8740	0.1969	1/4-28UNF	0.2165	19500	11300	0.39
SSUX05-14	7/8
SSUX05-15	15/16
SSUX05-16	1		62	38.1	19	15.9	22.2	5	M6*1	5.2
SSUX05		25
SSUX06-17	1 1/16		2.8346	1.6890	0.7874	0.6890	1.0000	0.2756	5/16-24UNF	0.2165	25700	15300	0.68
SSUX06-18	1 1/8
SSUX06-19	1 3/16
SSUX06-20	1 1/4		72	42.9	20	17.5	25.4	7	M8*1.0	5.5
SSUX06		30
SSUX07-20	1 1/4		3.1496	1.9370	0.8268	0.7480	1.1890	0.3150	5/16-24UNF	0.244	29500	18100	0.82
SSUX07-21	1 5/16
SSUX07-22	1 3/8
SSUX07-23	1 7/16
SSUX07		35	80	49.2	21	19	30.2	8	M8*1.0	6.2
SSUX08-24	1 1/2		3.3465	1.9370	0.8661	0.7480	1.1890	0.3150	5/16-24UNF	0.252	31600	20600	0.93
SSUX08-25	1 9/16
SSUX08		40	85	49.2	22	19	30.2	8	M8*1.0	6.4
SSUX09-26	1 5/8		3.5433	2.0315	0.9449	0.7480	1.2835	0.3937	3/8-24	0.256	35000	23200	1.00
SSUX09-27	1 11/16
SSUX09-28	1 3/4
SSUX09		45	90	51.6	24	19	32.6	10	M10*1.25	6.5
SSUX10-29	1 13/16
SSUX10-30	1 7/8		3.9370	2.1900	0.9843	0.8740	1.3150	0.3937	3/8-24	0.276	43500	29200	1.35
SSUX10-31	1 15/16
SSUX10-32	2		100	55.6	25	22.2	33.4	10	M10*1.25	7.0
SSUX10		50
SSUX11-32	2		4.3307	2.5630	1.0630	1.0000	1.5630	0.3937	3/8-24	0.335	47700	32900	1.90
SSUX11-33	2 1/16
SSUX11-34	2 1/8
SSUX11-35	2 3/16		110	65.1	27	25.4	39.7	10	M10*1.25	8.5
SSUX11		55
SSUX12-36	2 1/4		4.3307	2.5630	1.1024	1.000	1.563	0.394	3/8-24UNF	0.335	57500	40000	2.27
SSUX12-37	2 5/16
SSUX12-38	2 3/8
SSUX12-39	2 7/16
SSUX12		60	120	65.1	28	25.4	39.7	10	M10*1.25	8.5
